. AQV24PSBANXAX AQV24PSBAXXAX AQV30UWBNXSA AQV30UWBXXSA AQV24UWCNXSA AQV24UWCXXSA AQV30UWCXXSA AQV30UWCXXSA THE FEATURE OF PRODUCT Air Conditioner Mode AQV24UWCNXSA Mode can help you sleep quickly and soundly and wake up refreshed.

1. Service Manual Free Download
2. Samsung Manuals Online

Silence Mod ' e l i S, ' e experience extremely quiet operation of your AQV30UWCNXSA air conditioner. 5-3 Ass’y Control In.5-4 Ass’y Control Out.16. Electrical Parts List.17. Wiring Diagram.7-1 Indoor Unit.7-2 Outdoor Unit. Schematic Diagram.8-1 Indoor Unit.8-2 Outdoor Unit. Samsung Electronics.

14-6 Installation 14-9.14-7 Installation Diagram of Indoor Unit and Outdoor Unit 14-10.15-1.WORKING RANGE. 15-1 Power Supply 15-1.15-2 Working Range 15-1. 15-2-1 MULTIZONE/MONOZONE/SUMMIT 15-1.15-2-2 BIGFLOW 15-2.Samsung Electronics. good' sleep Mode good’sleep mode can help you sleep quickly and soundly and wake up refreshed.

Solutions & Tips, Download manuals and specs, Contact Us. Samsung Support NZ. The list of Samsung service manuals and Samsung repair manuals available for download on Nodevice in PDF, archives with additional service documents as schematics.

FULL HD FILTER Silver Nano Evaporator SPI (AQV24UWCXSA). AQV24UWCXSA AQV30UWCXSA Model Item Indoor Unit Outdoor Unit Indoor Unit Outdoor Unit Type Wall-mounted Wall-mounted Cooling Capacity (Low / Std / Max) i t a 10.0 12.0 Cooling Running Frequency (Low / Std / Max) i t a i d i i y f ℓ. 50dB 51dB Noise t i n 60dB 62dB FULL HD FILTER Air Purifying System Filter FULL HD FILTER p s i y a l p s i y a l p s i y a l Samsung Electronics. DB90-02738A (AQV24UWCXSA) DB70-00787A (AQV30UWCXSA) DB93-11489G DB98-32436A Holder remocon DB61-04899A. AQV24UWCNXSA AQV30UWCNXSA SMART SAVER. 3-3 Setting Option Setup Method SEG1 SEG2 SEG4 SEG5 SEG6 SEG7 SEG8 SEG9 SEG10 SEG11 SEG12 SEG13 SEG17 SEG18 SEG19 SEG20 SEG21 SEG22 SEG23 SEG24 SEG25 SEG26 SEG27 SEG28 SEG29 SEG30 SEG31 SEG32 SEG33 SEG34 SEG35 SEG36 Samsung Electronics. 3-3 Setting Option Setup Method(continue) Samsung Electronics.

AQV24UWCXSA SEG 16 017445 SEG 712 18428C SEG 50 Option Code SEG 1924 37F310 SEG 4954 034B53 SEG 45 AQV30UWCXSA SEG 16 018405 SEG 712 18423C SEG 5A Option Code SEG 1924 37F320 SEG 4954 034C45 SEG 3B. 3-4 EEPROM Downloading Method Samsung Electronics. FRONT.(use + Screw Driver) 4) Loosen connector wire(white) and detach the temperature sensor wire. 5) To detach the FRONT-PANEL the main frame, unfasten 2 screw at the bottom.(use + Screw Driver) 6) Take o the FRONT-PANEL,lifting up the bottom. Samsung Electronics. TRAY-DRAIN towards you.

CONTROL IN 1) Unfasten the earth screw.(use + Screw Driver) 2) Detach COVER-CONTROL from the CASECONTROL. 3) Detach the temperature sensor. 4) Loosen MOTOR Wire. 5) Take off the CASE-CONTROL from the main frame. Samsung Electronics. Operating Instructions and Installation Parts Procedure Remark 1) Unfasten the screw.

2) Cut the cable tie. 3) Loosen the terminal block wires. Caution: The terminal is locking type. So, when you separate terminals, pull pressing the button.

Button Samsung Electronics. 6) Loosen Main Power connector. Caution: When you separate the connector, pull pressing the locking button.

7) Loosen the Thermistor wire connector． Caution: When you separate the connector, pull pressing the locking button. 8) Loosen the Relay connector(Red,White). Samsung Electronics. 1) Unfasten the screw at the right side. (use + Screw Driver) 2) Unfasten the screw at the left side.

(use + Screw Driver) 3) Detach the HOLDER PIPE. 4) Take off the EVAPORATOR from the main frame. Samsung Electronics. 2) unfasten the 3 points screws in the CASE- CONTROL, and then detach the CASE.

(use + Screw Driver) 3) unfasten the screw a little.(use + Screw Driver) 4) Lift up the evaporator slightly and pull the CROSS-FAN to the left side. Samsung Electronics. Samsung Electronics.

Samsung Electronics. 4-10 Samsung Electronics. Samsung Electronics 4-11. 4-12 Samsung Electronics.

Operating Instructions and Installation 5. Exploded Views and Parts List 5-1 Indoor Unit ８ ７ Samsung Electronics. HIPS 6-8 DB94-00458D ASSY HOSE DRAIN ASSY DB96-11950K ASSY EVAP TOTAL ASSY 7-1 DB61-04580A HOLDER-EVAP HIPS DB94-02076A ASSY-CROSS FAN UNIT ASSY 8-1 DB94-00455B ASSY-RUBBER BEARING ASSY DB31-00589A MOTOR FAN DB31 00589A MOTOR FAN SIC-37CVJ-F127-3 SIC 37CVJ F127 3 Samsung Electronics. Q’TY AQV30UWCNXSA DB94-01498C DB61-03208A DB90-03402A ASSY-SUPPORT EVAP DB61-03215A BODY BACK-CUSHION DB61-03218A DB70-00787A PLATE HANGER DB92-02107L DB64-02517A DB63-01765E GUARD AIR FILTER DB90-05969A DB90-04933A DB90-05771A DB64-02516A DB64-02515C DB93-12594A DB93-10956C DB70-00778B PLATE COVER PBA DB94-01495D DB63-01755A DB61-03254A BLADE-V A 6-2-1 BLADE-V B 6-2-2 DB61-03255A DB61-04465A DB62-05974A INSULATION-HOSE. MODEL PARTS CODE PARTS DESCRIPTION SPEC SERVICE AQV24UWCXXSA AQV30UWCXXSA DB90-03918S ASSY CABI FRONT ASSY DB90-03918R ASSY CABI FRONT ASSY DB94-02034A ASSY GUARD FAN ASSY DB90-03278H ASSY BASE OUT ASSY DB90-03278C ASSY BASE OUT ASSY DB61-01593C BRACKET VALVE SGCC-M DB67-00861A FAN PROPELLER AS+GF20% DB60-30020A NUT HEXAGON FLANGE.

Model ＴＥＲＭＩＮＡＬ ＭＰＩ　ＷＩＲＥ. 5-4 Ass'y Control Out Model 5-10 Samsung Electronics. WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 3812-001283 J49 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 3812-001283 J5 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 3812-001283 J50 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 3812-001283 J51 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 3812-001283 J52 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm 3812-001283 J53 WIRE-NO SHEATH CU FE+CU+SN,300V,52mm(TAPING),1/0.6mm Samsung Electronics. R-CHIP 330ohm,5%,1/10W,TP,1608 2007-000076 R404 R-CHIP 330ohm,5%,1/10W,TP,1608 2007-000076 R601 R-CHIP 330ohm,5%,1/10W,TP,1608 2007-000076 R602 R-CHIP 330ohm,5%,1/10W,TP,1608 2007-000077 R116 R-CHIP 470ohm,5%,1/10W,TP,1608 2007-000078 R206 R-CHIP 1Kohm,5%,1/10W,TP,1608 2007-000078 R706 R-CHIP 1Kohm,5%,1/10W,TP,1608 2007-000078 R805 R-CHIP 1Kohm,5%,1/10W,TP,1608 2007-000078 R812 R-CHIP 1Kohm,5%,1/10W,TP,1608 2007-000078 R813 R-CHIP 1Kohm,5%,1/10W,TP,1608 Samsung Electronics. C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 2203-005249 C201 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 2203-005249 C401 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 2203-005249 C402 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 2203-005249 C508 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 2203-005249 C511 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 2203-005249 C514 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 2203-005249 C702 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 2203-005249 C704 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 2203-005249 C707 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 Samsung Electronics. 2007-001096 R714 R-CHIP 62Kohm,1%,1/10W,TP,1608 2007-001206 R711 R-CHIP 82Kohm,1%,1/10W,TP,1608 2203-000440 C709 C-CER,CHIP 1nF,10%,50V,X7R,TP,1608 2203-000440 C711 C-CER,CHIP 1nF,10%,50V,X7R,TP,1608 2203-005249 C710 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 2203-005249 C712 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 DB41-01021A PCB PCB SUB-HVPS FR-1,T1.6 DB93-11484A - ASSY PCB MANUAL BORACAY-PJT,SSEC 3711-005658 CN72 CONNECTOR-HEADER NOWALL,4P,1R,2mm,ANGLE,SN,WHT Samsung Electronics. INDOOR SUB PCB(DB93-10861A ) Parts Code Location DESC/SPEC Q'TY DB93-11450A - ASSY PCB AUTO;BORACAY-PJT,SSEC 0601-003048 LED5 LED;ROUND,GRN,3 PI,573mm,3.0x5.0mm 0601-003048 LED6 LED;ROUND,GRN,3 PI,573mm,3.0x5.0mm 0601-003048 LED7 LED;ROUND,GRN,3 PI,573mm,3.0x5.0mm 3404-001220 SW01 SWITCH-TACT;12V,50mA,160gf,6x6x5,SPST DB41-01017A PCB PCB SUB-DISPLAY;FR-1,T1.6 DB93-11451A - ASSY PCB SMD;BORACAY-PJ,SSEC 0401-001099 D01 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-323,TP 0504-000127 Q01 TR-DIGITAL;FJV3102R,NPN,200mW,10K/10Kohm,SOT-23,TP.

680nF,10%,275V,BK,31x11x21mm 2301-001949 C001 C-FILM,LEAD 3300nF,10%,275V,BK,31x21x31mm 2306-000123 C414 C-FILM,LEAD-PPF 100nF,5%,630V,BK,26x16.5x8.5mm 2306-000123 C806 C-FILM,LEAD-PPF 100nF,5%,630V,BK,26x16.5x8.5mm 2401-000481 CE109 C-AL 10uF,20%,50V,WT,TP,5x11,5 2401-000880 CE901 C-AL 220uF,20%,50V,WT,TP,10x16mm,5m 2401-001548 CE102 C-AL 47uF,20%,25V,WT,TP,5x11,5 2401-001838 CE104 C-AL 470uF,20%,25V,WT,TP,10x16,5 2401-001838 CE108 C-AL 470uF,20%,25V,WT,TP,10x16,5 2401-001838 CE110 C-AL 470uF,20%,25V,WT,TP,10x16,5 6-10 Samsung Electronics. 0506-000175 IC502 TR-ARRAY 2003,NPN,7,1W,SOP-16,ST,1000 0506-000175 IC503 TR-ARRAY 2003,NPN,7,1W,SOP-16,ST,1000 0601-002423 LED501 SMD,RED,1.6 X 3.2mm,639nm,1.6 X 3.2mm SMD(REVERSE),YEL,1.6x1.5mm,588nm,3.2x1.6x1 0601-002955 LED503.1mm 0601-002956 LED201 SMD(REVERSE),GRN,1.6x1.5mm,3.2x1.6x1.1mm 0601-002956 LED502 SMD(REVERSE),GRN,1.6x1.5mm,3.2x1.6x1.1mm 0604-001172 IC103 PHOTO-COUPLER TR,150-300,200mW,SOP,TP 0604-001172 IC106 PHOTO-COUPLER TR,150-300,200mW,SOP,TP 0604-001172 IC202 PHOTO-COUPLER TR,150-300,200mW,SOP,TP 6-11 Samsung Electronics. 4.7Kohm,5%,1/10W,TP,1608 2007-000084 R223 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 2007-000084 R224 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 2007-000084 R225 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 2007-000084 R227 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 2007-000084 R231 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 2007-000084 R407 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 2007-000084 R512 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 2007-000084 R513 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 2007-000084 R660 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 6-12 Samsung Electronics. 470Kohm,1%,1/4W,TP,3216 2007-000924 R658 R-CHIP 470Kohm,1%,1/4W,TP,3216 2007-000924 R659 R-CHIP 470Kohm,1%,1/4W,TP,3216 2007-000929 R110 R-CHIP 470ohm,1%,1/10W,TP,1608 2007-000939 R111 R-CHIP 47Kohm,1%,1/10W,TP,1608 2007-000939 R652 R-CHIP 47Kohm,1%,1/10W,TP,1608 2007-000950 R118 R-CHIP 47ohm,5%,1/4W,TP,3216 2007-000962 R107 R-CHIP 5.1Kohm,1%,1/10W,TP,1608 2007-000965 R523 R-CHIP 5.1Kohm,5%,1/10W,TP,1608 2007-000965 R524 R-CHIP 5.1Kohm,5%,1/10W,TP,1608 Samsung Electronics 6-13. 0.33nF,5%,50V,C0G,1608 2203-000783 C455 C-CER,CHIP 0.33nF,5%,50V,C0G,1608 2203-000799 C408 C-CER,CHIP 33nF,10%,16V,X7R,TP,1608 2203-002002 C218 C-CER,CHIP 0.033nF,5%,50V,NP0,TP,1608 2203-002002 C219 C-CER,CHIP 0.033nF,5%,50V,NP0,TP,1608 2203-002002 C220 C-CER,CHIP 0.033nF,5%,50V,NP0,TP,1608 2203-002002 C221 C-CER,CHIP 0.033nF,5%,50V,NP0,TP,1608 2203-002002 C222 C-CER,CHIP 0.033nF,5%,50V,NP0,TP,1608 2203-002002 C223 C-CER,CHIP 0.033nF,5%,50V,NP0,TP,1608 2203-002002 C451 C-CER,CHIP 0.033nF,5%,50V,NP0,TP,1608 6-14 Samsung Electronics. JUNGFRAU OUTDOOR INV MICOM,STM-1040-OA, DB91-01173A IC201 ASSY-MIC LM3S817, 48LQFP, ROM 64KB LM3S817,48,DC3V,50 MHz,LQFP,LQFP,LQFP,-40 DB09-00591A IC501 IC MICOM 85,64KB,LQFP Maldive Outdoor,STM-1042-OS, S3F4A1H, DB91-01178A IC501 ASSY-MIC 100TQFP, RAM 512KB S3F4A1H,100P,DC5V,12 MHz,TQFP,16 Bit,16 DB09-00535A IC501 IC MICOM Bit,TQFP,QFP,16 Bit,-40+105,512K Samsung Electronics 6-15.

Circuit Descriptions Circuit Descriptions 9-1-2 Outdoor Unit Samsung Electronics. ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ １ ＣＮ６１ ＳＴＥＰ　ＭＯＴＯＲ ２ ＣＮ２１ ＰＯＷＥＲ　ＩＮ ３ ＣＮ９１ ＤＩＳＰＬＡＹ ４ ＣＮ８１ ＭＰＩ ５ ＣＮ４３ ＴＥＭＰＥＲＡＴＵＲＥ　ＳＥＮＳＯＲ ６ ＣＮ３２ ＦＪＭ ７ ＣＮ７２ ＦＡＮ　ＭＯＴＯＲ ８ ＣＮ３１ ＤＯＷＮＬＯＡＤ ９ ＣＮ２１ ＣＯＭＭＵＮＩＣＡＴＩＯＮ.

Main parts Air filter(under the panel) Air intake Air flow blade (up and down) Blade pin lever Air flow blade (left and right) Display AQV09/12/18/24U AQV30U Remote control receiver Remote control receiver Operation indicator Operation indicator Timer indicator Timer indicator SPi indicator Smart Saver indicator Power. Remote controller display Power Smart Saver Mode Less energy usage makes your space Set one of the 5 operating modes cool between the temperature range (see pages 10-11 for instructions). Of 24°C30°C. Auto Clean Turbo Auto clean function – Dry inside of the indoor Operate in auto fan speed to unit to get rid of odor.

Is the communication error Terminate the service. Occurred again?

Is the connection of Correct the wrong cable communication cable normal? Exchange the Indoor unit’s PBA Terminate the service. Is the communication error occurred again?

Exchange the Outdoor unit’s PBA 12-2 Samsung Electronics. GOOD SLEEP PHOTO COUPLER SPI SELECT. 13-2 13-2 CONTROLLER ROOM TEMPERATURE SENSOR EEV CONTROL DISCHARGE TEMPERATURE SENSOR LED CONTROL INDOOR COMMUNICATION ROOM TEMPERATURE SENSOR EEPROM R/W OSCILLATION CIRCUIT BLDC FAN CONTROL PFC CONTROL COMPRESSOR CONTROL(BLDC) LED CONTROL OSCILLATION CIRCUIT AC ZERO CROSSING SIGNALCOMPRESSOR COMPRESSOR ZERO CROSSING SIGNAL BLDC FAN PULSE SIGNAL IPM FAULT SIGNAL DC VOLTAGE. Ex.) Maldives (Grille – White) Heat Pump12k Btu/h Model Indoor Unit (6) Project (7) Grille Color (8) Version (1), (2) Product Division Mont Blanc (Premium) SSEC Black Cooling Only Cry stal - Temporary Silver Max(including Smart) Heat Pump White - Temporary Mont Blanc (Deluxe) La Fleur (9) Unit. Note: Please measure the refrigerant pressure after the air conditioner operates on testing cooling mode during more than 10 minutes.
